closeIntroducing the 2023 Ikon Rakyat, now with three new color options and several new features to give you an enhanced riding quality.
The Modenas Kriss 110 (2023) uses a 4-Stroke, 1-Cylinder, 110 CC Air Cooled Engine with a 4-speed transmission. The model is able to produce 6.6 Hp of maximum power and 6.7 Nm maximum torque.
6.6 LITRE
USB CHARGING
Engine
4 Stroke SOHC, 1 Cylinder
Fuel System
Carburetor, PZ19
Displacement
108 cm3
Fuel Type
Unleaded Petrol
Capacity
110cc
Ignition
Magneto to CDI
Bore X Stroke
49.5 mm x 52.4 mm
Starting System
Primary Kick & Electric Starter
Compression Ratio
9.7:1
Cooling System
Air Cooled
Fuel Tank Capacity
4.2 L
Type
4 Speed, Rotary
Primary Reduction Ratio
4.058
Clutch
Multiple Disc, Centrifugal and Wet
Final Reduction Ratio
2.571
Driving System
Drive Chain
Frame Type
Pipe Backbone, Steel Pipe
Overall Length
1,868 mm
Front Suspension
Telescopic Fork
Overall Width
685 mm
Rear Suspension
Trailing Swing arm, Arm Suspension
Overall Height
1,185 mm
Front Brake
Drum
Ground Clearance
145 mm
Rear Brake
Drum
Wheelbase
1,235 mm
Front Tyre
70/90-17M/C 38P, Tubeless
Curb Weight
97 kg*
Rear Tyre
80/90-17M/C 44P, Tubeless
Battery
12v 5Ah
** The curb weight includes all materials and fluids required to operate properly, a full tank of fuel (over 90 percent capacity), and tool kit (if provided).
Read the Manual and all warnings on the product. Always wear a helmet, eye protection, and appropriate clothing for riding conditions. Never drive under the influence of drugs or alcohol. Follow the maintenance schedule in your Manual.
Specifications are subject to change.
